Fiat ABS Pumps – Complete ABS / ESP Units

Fiat ABS Pump: Hydraulic Module with ABS Control Unit

An ABS pump in a Fiat is an aluminium hydraulic block with valves and a pump motor, together with a control unit that reads the signals from the wheel speed sensors. On many models the same module also handles the stability control system, so a fault sometimes shows up as more than just the ABS warning light. The module is usually sold and replaced as a single unit.

Our range includes about twenty used original modules. Among them you will find original numbers, as well as Bosch (0 265 ... and 0 273 ...) and ATE (10.02..., 10.09..., 28.5266...) numbers. The range changes regularly, so the items below are only examples.

Fiat Punto, Stilo and Idea ABS Pump

For the popular compact models our range includes, among others:

• Fiat Punto ABS pump, number 46542381,
• Fiat Stilo ABS pump, number 0265231437,
• Fiat Idea ABS pump, number 46826210.

Fiat 500, Doblo and Marea ABS Pump

For the other models our range includes, among others:

• Fiat 500 ABS pump, number 52080678,
• Fiat Doblo ABS pump, number 00051924796,
• Fiat Marea ABS pump, number 00464415710.

Fiat Ducato ABS Pump

For the Ducato our range includes modules also described as Jumper and Boxer:

• Fiat Ducato Jumper ABS pump, number 46857734,
• Fiat Ducato Boxer ABS pump, number 46857735.

Modules shared by Fiat, Alfa Romeo and Lancia

Individual listings describe a module as shared by several brands, for example Fiat Alfa Romeo Lancia ABS pump, number 51896323, Fiat Lancia ABS pump, number 51902576 or Fiat Alfa Romeo ABS pump, number 46556475.

Fiat ABS pump: modules with no model stated

Most of the listings do not state the car model, for example Fiat ABS pump, number 46744771 and Fiat ABS pump, number P68145509AF. The listings do not always state the model and year, so compatibility depends on the number from the original pump.

How to choose an ABS pump for a Fiat by part number

Model and year are not enough, because the same model comes with different versions of the module, depending on the engine, drive and equipment level. In our range you will find several kinds of numbers:

• the original number, most often eight-digit, for example 46542381 or 51896323, in some listings eleven-digit, for example 00464415710, and in individual listings in the form P68145509AF,
• the manufacturer's number for the hydraulic block, for example Bosch 0 265 2xx xxx or ATE 10.02xx-xxxx.x,
• the control unit number, for example Bosch 0 265 9xx xxx, Bosch 0 273 004 xxx or ATE 10.09xx-xxxx.x.

Compare all the numbers with the original pump in your car and, if in doubt, write to us before buying.

Symptoms of a faulty ABS pump or control unit

• the ABS warning light comes on after the engine is started and does not go out,
• the ABS stops working, although basic braking usually remains functional,
• the brake pedal pulses or feels uneven for no obvious reason,
• the control unit stores valve, pump motor or communication faults,
• brake fluid leaks from the hydraulic block, which requires immediate action.

Before deciding on a replacement, check the wheel speed sensors, their wiring and the supply voltage. After replacing the module, the fault codes usually need to be cleared, and after disconnecting the brake lines the system must be bled. On some models the module also needs adaptation in the control unit, so installation is best left to a workshop with a suitable diagnostic scanner.

Used original ABS module: condition and inspection

We sell used original ABS modules, not new parts. Every item is inspected and tested before sale, and the product photos show the look of the block, the numbers and the labels, so you can compare them with your own pump.
