ABS pump and control module Audi Volkswagen Seat ATE 3Q0614517C 10022005264 3Q0907379C 10062239331
Vendors's code: 3Q0614517C
Product code: 10022005264
Barcode:
Code 39:
ISBN:
£247.16
Price
£247.16
£304.01
Price
£304.01
Ask about the product
ABS pump and control module Audi Volkswagen Seat ATE 3Q0614517C 10022005264 3Q0907379C 10062239331
Administratorem danych osobowych jest Auto24parts. Przetwarzamy je w celu przesłania odpowiedzi na zapytanie. Więcej informacji dotyczących przetwarzania danych osobowych znajduje się w polityce prywatności.
Shipping
from
£22.80
-
shipping
(Poland)
from
£22.80
-
shipping
(Poland)
Price 30 euros applies shipments to 5 kg on worldwide. Above this weight, please contact us by email to check price
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Does ABS pump 3Q0614517C fit your Audi?
Yes, if your unit shows the same number 3Q0 614 517 C and the control module is marked 3Q0 907 379 C. This used, working ATE hydraulic unit was fitted to Audi, Volkswagen and Seat cars.
3Q0614517C - ATE unit with control module 3Q0907379C
There are five markings on this item, each with its own purpose. The VAG numbers - 3Q0614517C for the pump and 3Q0 907 379 C for the module - are the basis for matching in Audi, Volkswagen and Seat cars. The other three come from ATE: 10.0220-0526.4 describes the hydraulic block, while 10.0622-3933.1 and 28.5154-7112.3 are on the control module label. The manufacturer's numbers are handy when you want extra confirmation of the identification.
Five numbers from this unit
- 3Q0614517C - VAG number of the ABS pump (hydraulic unit), on the sticker: 3Q0 614 517 C
- 10022005264 - ATE number of the hydraulic block (pump), written as: 10.0220-0526.4
- 3Q0907379C - VAG number of the ABS/ESP control module, label: 3Q0 907 379 C
- 10062239331 - ATE number from the control module label, recorded as 10.0622-3933.1
- 28515471123 - second ATE number from the control module label: 28.5154-7112.3
The pump has a paper sticker on its motor housing with numbers and DataMatrix codes; the control module has a label reading ‘Controller’ and ‘Steuergeraet ESC’. The shop has one more version of this pump with a different suffix, so note the letter C at the end of 3Q0 614 517 C.
Symptoms that call for a check of the unit
A fault is usually suspected when you see:
- the ABS and ESP lights on at the same time,
- ABS inactive during braking,
- a recorded pump fault.
Before replacing it, check the fault memory with a scan tool and rule out faults in the wheel speed sensors, fuses, wiring and connector, as well as low battery voltage. After fitting, the system has to be bled; on many VW Group cars the module requires coding, and with ESP a basic setting of the steering angle sensor is usually performed.
Questions about ABS pump 3Q0614517C
| Which cars was this unit fitted to? |
|---|
| Audi, Volkswagen and Seat cars. We do not give a specific model - you confirm the fit using the pump and control module numbers. |
| What condition is the unit in, and is there a warranty? |
| It is a used, working, genuine ATE part. The warranty period is shown in the product features table. |
| Does the control module need coding after fitting? |
| On many VW Group cars, yes - coding is done with a diagnostic tool. With ESP, a sensor calibration is usually needed too. |
| Does the brake system need bleeding? |
| Yes. Once the brake lines have been disconnected, this step is essential - without it the brakes will not work properly. |
If you want to be certain, send us a photo of the sticker with the DataMatrix codes from your pump, or your VIN.
