Engine Control Unit Volkswagen 06A906033AS 5WP4015102
Vendors's code: 5WP4015102
Product code: 06A906033AS
Barcode:
Code 39:
ISBN:
€203.25
Price
€203.25
€250.00
Price
€250.00
Select a product option:
Individual variants may differ in price
product option
Important: Depending on the ECU type and vehicle model, not all of the options listed below may be available.
To select the correct option for your vehicle and ECU, please contact us before purchasing:
contact@auto24parts.com
1. Locked
This option is intended for professional workshops with the required specialist equipment and technical knowledge.
The ECU has been removed from a vehicle intended for recycling and still contains the immobilizer data and other information from the previous vehicle. Before it can be used in another car, it must be unlocked and then programmed using specialist automotive diagnostic equipment.
2. Unlocked
Several preparation methods may be available. The possible options depend on the ECU type, vehicle model and immobilizer system. Please contact us before purchasing, as some preparation methods are not available for every ECU.
Our electronics specialists can prepare the ECU in one of the following ways:
a) ECU with PIN code (Car Pass)
The PIN code is supplied, but programming with a suitable diagnostic tool is still required. After installing the ECU, it must be reset using the supplied PIN code and then programmed to the vehicle’s immobilizer system.
b) VIRGIN ECU
The data from the previous vehicle is removed and the ECU is restored to a clean, factory-like state. After installation, it must be programmed to the vehicle using a compatible specialist diagnostic tool. Unless another preparation method is specified in the product description, this is the standard unlocking option for most of our ECUs.
c) Plug & Play – IMMO OFF
The immobilizer function is disabled in the ECU. After installation, the engine can start without additional immobilizer programming. Please note that the vehicle will no longer have an active immobilizer function, and an immobilizer warning light or fault code may remain, depending on the vehicle model.
d) Plug & Play – Automatic Programming
After installation, the ECU automatically learns and saves the required vehicle data. No additional programming is normally required.
e) Plug & Play – 1:1 Clone
The data from your original ECU is copied to another fully functional ECU. The cloned unit is then ready for installation without additional programming.
You must send us your original ECU so that we can transfer its data to the replacement unit.
The original ECU must have working communication with the vehicle, a diagnostic tool or our programming equipment. If the required data cannot be read, a complete 1:1 clone may not be possible.
3. Complete Plug & Play Set
A complete matched set containing the ECU, immobilizer components and all other parts required to start the vehicle without additional programming. All components supplied in the set must be installed in the vehicle.
Important:
Dispatch time depends on the selected option. If an unlocked or specially prepared version is ordered, the preparation service usually requires an additional 1–2 business days.
Ask about the product
Engine Control Unit Volkswagen 06A906033AS 5WP4015102
Administratorem danych osobowych jest Auto24parts. Przetwarzamy je w celu przesłania odpowiedzi na zapytanie. Więcej informacji dotyczących przetwarzania danych osobowych znajduje się w polityce prywatności.
Shipping
from
€30.00
-
shipping
(Poland)
from
€30.00
-
shipping
(Poland)
Price 30 euros applies shipments to 5 kg on worldwide. Above this weight, please contact us by email to check price
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
How do you check whether the 06A906033AS ECU will fit?
Compare the label on your ECU with the numbers 06A906033AS and 5WP40151 02. This used, working unit for a petrol Volkswagen is available in two versions.
Engine Control Unit Volkswagen 06A906033AS 5WP4015102
The VW number 06A906033AS indicates an engine control unit, and the AS ending its version. The unit comes from a petrol-engined Volkswagen and carries a second number on its casing, 5WP4015102. It is responsible for fuel injection, ignition and smooth engine running. The unit is used, in working order and in good condition.
Numbers to compare
- 06A906033AS – VW part number
- 5WP4015102 – 5WP… number (Siemens VDO / Continental numbering), shown on the label as 5WP40151 02
When matching the unit, pay attention to the letters AS – 06A906033 ECUs with a different ending (e.g. DC or DR) are separate software or hardware versions. If the label is worn, send us a photo of it and we will help you read the numbers.
Symptoms of a faulty unit
- the engine will not start despite having a spark and fuel,
- hunting idle speed,
- internal ECU faults,
- no communication with the tester.
First check the ECU's power supply, earths and plug – these are the most common sources of similar faults. It is also worth reading the fault codes before deciding to replace the unit.
Choosing a variant
You can order the 06A906033AS ECU locked – with the previous car's data and immobiliser, for workshops that will unlock, program and match it themselves – or unlocked, prepared by us before dispatch (usually 1–2 working days).
Not every preparation method (PIN / CAR PASS, Virgin, IMMO OFF, auto programming, clone) is possible; it depends on the part number, software and immobiliser. Ask before you buy. Description: ECU preparation options.
Questions and answers
| Will the 06A906033AS replace the 06A906033DR? |
|---|
| Do not assume they are interchangeable – they are different versions. |
| What does the 5WP number look like on the label? |
| Usually 5WP40151 02, i.e. with a space before the last two digits. |
| How long does it take to prepare the unlocked version? |
| Usually 1–2 working days. |
| What condition is the unit in? |
| Used, in working order, in good condition. You will find the warranty period in the product features table. |
If you would like to confirm compatibility, email contact@auto24parts.com.
