The automatic transmission control unit (often designated as TCU or TCM) is a crucial electronic component responsible for smooth and trouble-free gear shifting. Its failure, most often caused by overheating, short circuits, or water damage, results in jerking, an inability to shift gears, or the vehicle entering limp mode. Purchasing a new module at an authorized dealership is a massive expense, which is why replacing it with a fully functional, used original is the most reasonable solution.
ECU ENGINE CONTROLLER ALFA ROMEO 1.9 JTD BOSCH 0281011425 55193517
Vendors's code:
Product code: E674-385CA
Barcode:
Code 39:
ISBN:
€162.60
Price
€162.60
€200.00
Price
€200.00
Select a product option:
Individual variants may differ in price
product option
Important: Depending on the ECU type and vehicle model, not all of the options listed below may be available.
To select the correct option for your vehicle and ECU, please contact us before purchasing:
contact@auto24parts.com
1. Locked
This option is intended for professional workshops with the required specialist equipment and technical knowledge.
The ECU has been removed from a vehicle intended for recycling and still contains the immobilizer data and other information from the previous vehicle. Before it can be used in another car, it must be unlocked and then programmed using specialist automotive diagnostic equipment.
2. Unlocked
Several preparation methods may be available. The possible options depend on the ECU type, vehicle model and immobilizer system. Please contact us before purchasing, as some preparation methods are not available for every ECU.
Our electronics specialists can prepare the ECU in one of the following ways:
a) ECU with PIN code (Car Pass)
The PIN code is supplied, but programming with a suitable diagnostic tool is still required. After installing the ECU, it must be reset using the supplied PIN code and then programmed to the vehicle’s immobilizer system.
b) VIRGIN ECU
The data from the previous vehicle is removed and the ECU is restored to a clean, factory-like state. After installation, it must be programmed to the vehicle using a compatible specialist diagnostic tool. Unless another preparation method is specified in the product description, this is the standard unlocking option for most of our ECUs.
c) Plug & Play – IMMO OFF
The immobilizer function is disabled in the ECU. After installation, the engine can start without additional immobilizer programming. Please note that the vehicle will no longer have an active immobilizer function, and an immobilizer warning light or fault code may remain, depending on the vehicle model.
d) Plug & Play – Automatic Programming
After installation, the ECU automatically learns and saves the required vehicle data. No additional programming is normally required.
e) Plug & Play – 1:1 Clone
The data from your original ECU is copied to another fully functional ECU. The cloned unit is then ready for installation without additional programming.
You must send us your original ECU so that we can transfer its data to the replacement unit.
The original ECU must have working communication with the vehicle, a diagnostic tool or our programming equipment. If the required data cannot be read, a complete 1:1 clone may not be possible.
3. Complete Plug & Play Set
A complete matched set containing the ECU, immobilizer components and all other parts required to start the vehicle without additional programming. All components supplied in the set must be installed in the vehicle.
Important:
Dispatch time depends on the selected option. If an unlocked or specially prepared version is ordered, the preparation service usually requires an additional 1–2 business days.
Ask about the product
ECU ENGINE CONTROLLER ALFA ROMEO 1.9 JTD BOSCH 0281011425 55193517
Administratorem danych osobowych jest Auto24parts. Przetwarzamy je w celu przesłania odpowiedzi na zapytanie. Więcej informacji dotyczących przetwarzania danych osobowych znajduje się w polityce prywatności.
Shipping
from
€30.00
-
shipping
(Poland)
from
€30.00
-
shipping
(Poland)
Price 30 euros applies shipments to 5 kg on worldwide. Above this weight, please contact us by email to check price
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Engine Control Unit Alfa Romeo 1.9 JTD Bosch 0281011425
The engine control unit 0281011425 (0 281 011 425, 55193517) is a proven component that helps restore proper and stable operation of the 1.9 JTD engine in Alfa Romeo vehicles.
ENGINE CONTROL UNIT ALFA ROMEO 1.9 JTD BOSCH 0 281 011 425, 0281011425, 55193517
Below you will find short information about the Bosch engine control unit with part numbers 0 281 011 425, 0281011425 and 55193517, used in Alfa Romeo vehicles with the 1.9 JTD engine.
Which models does ECU 0 281 011 425 fit?
This ECU was installed in Alfa Romeo vehicles with the 1.9 JTD engine (e.g. 146, 147, 156, GT). Part numbers 0 281 011 425, 0281011425 and 55193517 refer to the same engine control unit. The best way to confirm compatibility is by checking the vehicle VIN number.
Do 0281011425 and 55193517 refer to the same ECU?
Yes — all listed numbers refer to the same engine control module. The differences are only due to various catalog number formats used by the vehicle manufacturer and the electronics supplier. If the numbers match, the ECUs are interchangeable.
What symptoms may indicate a faulty ECU?
The most common symptoms include starting problems or rough engine operation, especially at low RPM. The vehicle may lose power or enter limp mode, and diagnostic communication issues may occur. These symptoms often indicate an ECU problem.
Does this ECU require programming?
Yes — after installation, the ECU usually needs to be matched to the specific vehicle. This process includes immobilizer adaptation and ECU parameter coding and should be performed by an automotive electronics specialist. After programming, the module operates correctly.
