Isuzu ABS Pumps and Control Units – D-Max & Grafter
Isuzu ABS Pumps – D-Max and Grafter
Auto24Parts offers used original ABS pumps and control units for Isuzu vehicles, including selected Isuzu D-Max and Isuzu Grafter applications. The complete assembly combines the hydraulic ABS unit with its electronic controller.
The safest way to choose the correct Isuzu ABS pump is to compare the complete OEM number, hydraulic-unit number and ABS ECU number with the original part. Current catalogue examples include Isuzu D-Max 0265292559 / 898394765 / 0265956879 and Isuzu Grafter units 898250132 / 1338002740 and 898320280 / 1338002060.
For example, see the Isuzu Grafter ABS pump 898250132 / 1338002740.
If the numbers on your original unit are different, send us a clear photo of the ABS pump and control-unit labels before ordering.
List of products
Isuzu ABS Pump and Control Unit – Complete Hydraulic Assembly
A complete Isuzu ABS pump normally combines the hydraulic braking unit with an electronic ABS control module. Depending on the vehicle configuration, the controller can also communicate with stability and traction-control systems.
In this category, the focus is specifically on ABS pumps fitted to Isuzu vehicles. Current catalogue applications include Isuzu D-Max and Isuzu Grafter, with Bosch and ADVICS systems represented.
How to choose the correct Isuzu ABS pump
ABS assemblies can look very similar while using different hydraulic blocks, electronic controllers or internal configurations. For this reason, the vehicle model alone is not enough to confirm compatibility.
Before ordering, compare:
- the complete Isuzu OEM number,
- the hydraulic ABS pump number,
- the electronic ABS controller number,
- the manufacturer name such as Bosch or ADVICS,
- all suffix letters and final digits,
- vehicle model and production year as supporting information.
The complete combination of numbers from the original ABS assembly is the safest basis for selecting a replacement.
Isuzu D-Max ABS pump – 0265292559 / 898394765 / 0265956879
One of the Isuzu D-Max ABS units in the catalogue carries three important references:
- Bosch 0265292559,
- Isuzu 898394765,
- ABS control unit 0265956879.
When searching for this unit, it is worth using all three numbers rather than only one reference.
Useful search phrases include:
- Isuzu D-Max ABS pump 0265292559,
- Isuzu ABS pump 898394765,
- Isuzu D-Max ABS ECU 0265956879,
- Bosch ABS pump 0265292559 0265956879,
- Isuzu D-Max 898394765 0265956879.
Why does the Isuzu D-Max ABS pump have several numbers?
A complete ABS assembly can carry separate identifiers for different parts of the unit. One number may identify the hydraulic component, another may identify the electronic controller, while an Isuzu OEM reference identifies the vehicle-specific assembly.
That is why comparing only 0265292559 or only 0265956879 may provide less information than checking the full set 0265292559 / 898394765 / 0265956879.
Bosch ABS systems for Isuzu D-Max
Bosch is one of the manufacturers represented in the Isuzu ABS category.
The D-Max example uses:
- 0265292559 – one of the Bosch references on the assembly,
- 0265956879 – the electronic ABS controller reference,
- 898394765 – the Isuzu-related OEM reference.
Bosch number families contain many different ABS versions, so a shared prefix such as 0265... does not confirm compatibility. The complete number should be compared.
Isuzu Grafter ABS pump – 898250132 / 1338002740
Another confirmed Isuzu application is the Isuzu Grafter ABS pump and control unit 898250132 / 1338002740.
Important references:
- 898250132,
- 1338002740.
This unit is associated with an ADVICS ABS system. Both numbers should be checked against the original unit before installation.
Isuzu Grafter ABS pump – 898320280 / 1338002060
A second Grafter version in the catalogue uses:
- 898320280,
- 1338002060.
This is a different full reference from 898250132 / 1338002740. The fact that both units are used in Isuzu Grafter vehicles does not mean that they are automatically interchangeable.
Two Isuzu Grafter ABS versions – check the exact numbers
Compare the current catalogue examples:
- 898250132 / 1338002740,
- 898320280 / 1338002060.
Both belong to the same vehicle family, but each uses a different combination of part and control-unit numbers.
This is why searching only for “Isuzu Grafter ABS pump” is useful for browsing but not sufficient for final part identification.
ADVICS ABS units in Isuzu vehicles
ADVICS is represented in the current Isuzu Grafter catalogue. These units can carry manufacturer references such as 133800... together with Isuzu-specific numbers.
Examples include:
- 1338002740 / 898250132,
- 1338002060 / 898320280.
The complete ADVICS and Isuzu numbers should be compared together whenever possible.
ABS pump vs ABS control unit
A complete ABS pump normally contains both the hydraulic section and electronic controller.
The complete assembly can include:
- hydraulic valve block,
- ABS pump motor,
- solenoid valves,
- electronic ABS control unit.
If only the electronic module is required, see the separate ABS / ESP / ASR control units category.
Common symptoms of an Isuzu ABS system problem
Possible symptoms can include:
- ABS warning light remaining on,
- ESP or traction-control warning where fitted,
- loss of ABS intervention,
- diagnostic fault codes stored in the braking system,
- loss of communication with the ABS controller,
- pump-motor or hydraulic-valve fault codes,
- intermittent ABS operation.
These symptoms do not automatically prove that the ABS pump is faulty.
Does an ABS warning light always mean the pump is damaged?
No. Before replacing the complete unit, other parts of the braking and electrical system should also be checked.
Possible causes can include:
- wheel-speed sensors,
- sensor wiring,
- damaged connectors,
- power supply or ground faults,
- fuses and relays,
- communication wiring,
- hydraulic faults,
- problems elsewhere in the braking or stability-control system.
Diagnostic fault codes and live sensor data can help narrow down the cause before replacing the ABS assembly.
No communication with the Isuzu ABS controller
If diagnostic equipment cannot connect to the ABS module, check:
- power supply to the controller,
- ground connections,
- relevant fuses,
- connector pins,
- corrosion or water ingress,
- CAN or other communication wiring.
A failed electronic controller can cause loss of communication, but a wiring or power-supply problem can produce the same symptom.
Does an Isuzu ABS pump require coding after replacement?
There is no single coding procedure that applies to every Isuzu ABS unit.
Depending on the model, system generation and replacement part, installation may require:
- diagnostic verification,
- coding or configuration,
- basic settings,
- calibration of related sensors,
- clearing stored fault codes after the repair.
Other systems may use a simpler replacement procedure. Requirements should therefore be confirmed for the exact vehicle and ABS part number.
Bleeding the brake system after ABS pump replacement
Replacing a complete hydraulic ABS pump normally involves opening the brake hydraulic system. The system must therefore be bled correctly after installation according to the vehicle manufacturer's service procedure.
Depending on the vehicle, diagnostic equipment may be needed to activate internal valves or the pump during the bleeding procedure.
Because the ABS unit is part of the braking system, installation should be performed by a suitably qualified workshop.
Used original Isuzu ABS pumps
A used original ABS assembly can be a practical replacement when the exact part-number combination matches the original vehicle unit.
For automotive electronics and hydraulic brake components, compatibility depends on the exact configuration. This is why the part numbers should be checked before purchase rather than relying only on the model name or visual appearance.
How to search for an Isuzu ABS pump by part number
Useful searches include:
- Isuzu D-Max ABS pump 0265292559,
- Isuzu D-Max ABS controller 0265956879,
- Isuzu D-Max ABS 898394765,
- Isuzu Grafter ABS pump 898250132,
- Isuzu Grafter ABS ECU 1338002740,
- Isuzu Grafter ABS 898320280 1338002060,
- ADVICS Isuzu ABS 1338002740,
- Bosch Isuzu ABS 0265956879.
Searching with two or three numbers from the original unit normally provides much more precise results than searching only by vehicle model.
Selected Isuzu ABS pumps
The current Isuzu range includes the D-Max ABS assembly 0265292559 / 898394765 / 0265956879 together with two Isuzu Grafter configurations: 898250132 / 1338002740 and 898320280 / 1338002060.
If your original unit uses another number, compare every reference before selecting a replacement.
Related ABS and electronic categories
How to confirm compatibility before ordering
If you are unsure which Isuzu ABS pump is correct, contact Auto24Parts.
For verification, send:
- a clear photo of the complete ABS assembly,
- a photo of the electronic controller label,
- the hydraulic-unit number,
- all Bosch or ADVICS references,
- vehicle model,
- production year.
For ABS assemblies, comparing the complete set of numbers is usually more reliable than the vehicle model alone.
Ordering, Payment, Delivery and Returns
Ordering information is available in our How to Buy guide. Payment options are listed under Secure Payment Methods, while shipping information can be found on the Shipping & Delivery page.
Current information about returns, complaints and warranty is available under Returns, Warranty & Complaints.
FAQ – Isuzu ABS Pumps and Control Units
| Question | Answer |
|---|---|
| How do I choose the correct ABS pump for my Isuzu? | Compare the complete OEM, hydraulic-pump and ABS-controller numbers with the original unit. The model and year are useful supporting information, but the complete part numbers are more precise. |
| Which ABS pump numbers are used on the Isuzu D-Max in your catalogue? | One current D-Max assembly carries the references 0265292559, 898394765 and 0265956879. All numbers should be compared with the original part before ordering. |
| What does Bosch 0265956879 identify? | 0265956879 is the electronic ABS-control reference used on the Isuzu D-Max unit in the catalogue. It should be checked together with 0265292559 and 898394765. |
| Which Isuzu Grafter ABS pump numbers are available? | Current catalogue examples include 898250132 / 1338002740 and 898320280 / 1338002060. These are different full references and should not automatically be treated as interchangeable. |
| Are 1338002740 and 1338002060 the same ABS controller? | No. They are different full references. Always compare the corresponding Isuzu number as well as the electronic-controller number. |
| What is the difference between an ABS pump and an ABS control unit? | The ABS control unit is the electronic controller. A complete ABS pump normally combines this electronics module with the hydraulic valve block and pump motor. |
| Does an ABS warning light mean the Isuzu ABS pump is faulty? | Not necessarily. Wheel-speed sensors, wiring, power supply, connectors or other braking-system faults can cause similar warning lights. Diagnostic testing is recommended before replacement. |
| Does no communication mean the ABS controller has failed? | Not always. Power, ground, fuses, connectors and communication wiring should also be checked before concluding that the electronic controller is damaged. |
| Does a used Isuzu ABS pump always require coding? | No universal rule applies to every Isuzu ABS system. Some vehicle versions may require coding, configuration or basic settings, while others can use different installation procedures. |
| Does the brake system need bleeding after replacing the complete ABS pump? | Replacing the hydraulic assembly opens the brake circuit, so the system must be bled according to the manufacturer's repair procedure. Some vehicles may require diagnostic activation of the pump or valves. |
| Can I select an Isuzu ABS pump using only the vehicle model? | No. Isuzu D-Max and Grafter vehicles can use different ABS versions. Compare all numbers from the original hydraulic unit and electronic controller. |
| What information should I send to confirm compatibility? | Send clear photos of the original ABS pump and electronic-controller labels, all visible part numbers, the Isuzu model and production year. |
